Sharp Professional PN-V600A 60” LED Backlight Display
×

The Sharp Professional PN-V600A is designed for sophisticated video wall applications, this video wall monitor offers the world's slimmest bezel available on a 60" class (60" diagonal) LCD display. As a flexible digital signage solution with 24/7 certified reliability and an almost seamless bezel (just 6.5 mm total between neighboring monitors), the PN-V600A helps set a new standard for video wall displays. Its full-array LED backlight helps ensure uniform brightness and an enlarge (zoom) display mode enables one image to be expanded across up to 25 monitors (in a 5x5 configuration).

Polycom Ceilling Microphone Array
×

The Polycom Ceilling Microphone Array provides complete room coverage with superior audio pickup. This microphone array picks up voices in a 360-degree area, giving focus to the active speaker without physical intervention. This microphone supports stereo audio with Polycom Siren 22 audio technology, increases the flexibility of room use by putting electronics in the ceiling instead of the floor or tabletop and connects directly to the Polycom videoconferencing systems and installed audio solutions.

Crestron TSW-1050
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics™. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Sharp AQUOS HD LC-70LE650U
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Barco ClickShare
×

ClickShare’s universal USB-powered Button and ClickShare app for iOS and Android avoids the unsightly jumble of cables often seen in meeting rooms. It requires no special adaptor or port – so there’s no need to carry additional wires or rummage under the table. And with no cables, you’ll spend less time setting-up and more time being productive. ClickShare couldn’t be simpler. Everything works with the tap of a button, leaving nothing more to figure out. Connecting ClickShare does not alter your screen size or resolution, so what you see on your laptop screen is replicated on the big meeting room screen. When you plug in a ClickShare Button, there’s no software to download and install. You simply accept an executable file and you’re ready to go. Once finished, ClickShare leaves no software on your PC or Mac. Whether you present from a PC, Mac, tablet or smartphone, ClickShare has it covered. As well as the USB-powered ClickShare Button, the ClickShare app for iOS and Android expands meeting effectiveness to include content sharing from mobile devices.

Crestron DM-MD 16x16 DigitalMedia™ Switcher
×

A fully modular and expandable 16x16 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, as well as computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

Crestron AV3
×

A rack-mountable 3-Series® control processor offering immense power, expandable memory, numerous integrated control ports and optional control card expansion slots. Features an isolated control subnet providing a Gigabit Ethernet LAN dedicated for Crestron devices.

Polycom SoundStructure C-Series C16 Audio Mixer
×

The SoundStructure C-Series delivers clear, immersive sound, so your video and voice conferences are more productive. The unmatched performance and clarity will delight meeting participants. SoundStructure C-Series also integrates easily with Polycom Group and HDX Microphones, which leads to faster integration and better performance.

Irving Boardroom Irving, TX

Audio, Boardroom, Conferencing, Video

In today’s executive meeting environment it is extremely important to include a high level of audio-visual presentation and communication equipment enabling the leadership to shape and grow your business in a most effective way. The users of this space can share content from a static PC, through wired connections around the table and through the wireless abilities of Apple TV and Barco’s ClickShare. Utilizing a 2x2 video wall, made up of 60” LED displays, as well as (4) 70” LED displays around the sides the users don’t have to strain to see and can collaborate over multiple pieces of content at any time. Cisco HD video conferencing and integration of VoIP audio conferencing give users the ability of reaching their partners and customers. Microphones in the ceiling and premium ceiling speakers give the users the best possible audio experience. Finally, simplistic auto input detection as well as drag and drop control, via a table top touch panel, makes the room user friendly.



Off Screen Components Used

Cisco TelePresence Precision Cameras make your face-to-face video meetings lifelike and immediate. The cameras can optimize every telepresence and high-definition video experience with sharpness and clarity. The Cisco TelePresence Precision Camera portfolio offers four powerful cameras with 1080p60 resolution for easy integration into huddle spaces, small-to-large meeting rooms, boardrooms, and special industry projects.
The Cisco TelePresence C40 Video Conferencing Unit provides a powerful and flexible platform for creating the ultimate video collaboration experience. The C40 was built with the integrator in mind to support flexibility and creativity for customized video collaboration rooms that delight customers.
The Extron XTRA Series XPA 2002 is a half rack 1U, convection cooled power amplifier delivering 200 watts into a 70 volt or 100 volt line. This professional grade amplifier features a 100 dB signal-to-noise ratio with less than 0.1% THD+N. The XPA 2002 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers.
The NE1 provides solid steel construction, extra space on the bottom of the rack for easily mounting small components and two removable 3U blanks on top for ventilation options, this enclosed rack is packed with features that installers have been asking for. L-Shaped tie bars feature oblong cutout on both sides of the L to keep cables tidy and well organized.
The Extron Cable Cubby® 600 is a durable, metal enclosure that can be mounted into a tabletop or other flat surface. The Cable Cubby's lid slides out of the way when it is fully open and lifts easily to close. When the cables are not being used, they can be stored out of sight while remaining connected to the system, offering a discreet way to access cables and connection points as they are needed. The Cable Cubby 600 is available in a brushed aluminum finish. AC power modules are available for the US, Europe, and other major world markets

RELATED PROJECTS

Crestron TSW-1050
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Da-Lite Tensioned Advatage Electrol Ceiling Recessed 137" Projection Screen
×

Designed to eliminate the extra step of finishing the screen with trim, the Advantage line of projection screens is designed with ceiling trim already in place. An enhanced drive mechanism to keep your screen whisper quiet and a patent pending roller technology to keep your screen perfectly flat. A slim-Tab design provides a lower profile, stronger tab design to keep your screen perfectly tensioned.

Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
×

A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

Clearone Converge Pro 880TA
×

The CONVERGE Pro 880TA is a complete conferencing system featuring an automatic, digital matrix mixer, eight microphone inputs and an integrated, four-channel power amplifier for the sharpest audio experience with the unmatched sound quality you expect from ClearOne. Ideal for collaboration, presentation and distance communications, the expandable CONVERGE Pro 880TA solution fits virtually any venue or application with Distributed Echo Cancellation®, Noise Cancellation, First Microphone Priority and the ability to support up to 96 microphones.

Polycom RealPresence Group 700
×

The Polycom RealPresence Group Series is the engine that drives enterprise-grade video, voice and collaboration experiences, accelerating decision-making and fostering innovation. Only Polycom delivers video collaboration experiences that bring users closer together and drive meaningful conversation for geographically dispersed teams.

Ft Worth Boardroom Ft. Worth, TX

Audio, Boardroom, Conferencing, Video

Today’s users show content in many different formats.  This customer wanted to be able to accommodate all presenters while still making the room user friendly. The room is outfitted with a large format LED display on one side of the room while a high definition LCD projector and HD Progressive fabric projection screen resides on the other. Small ‘button’ style microphones with LED indicator rings are installed in the table for use with audio and video conferencing functions. Polycom’s Group Series video conferencing system gives this user the ability of reaching any of their partners across the globe. Room control, including the shades and lighting, is done through a Crestron touch panel on the table. By masking the equipment in the customer’s credenza, the room stays clutter free and gives users a very comfortable and effective conferencing space.



Off Screen Components Used

The Polycom® EagleEye IV 12x cameras are specifically designed for the Polycom RealPresence Group Series video systems. With a completely digital sensor to capture incredible detail, these cameras also have a wide field of view making them flexible enough to use in any room environment, from a small huddle room to a large boardroom. Includes High-definition capture of up to 1080p60 12x or 4x zoom options available, with 180-degree panning - radius a perfect fit for different environments and applications
The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.
The Extron XTRA Series XPA 2001 is a half rack 1U, convection cooled power amplifier delivering 200 watts into a 70 volt or 100 volt line. This professional grade amplifier features a 100 dB signal-to-noise ratio with less than 0.1% THD+N. The XPA 2001 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers.
The NE1 provides solid steel construction, extra space on the bottom of the rack for easily mounting small components and two removable 3U blanks on top for ventilation options, this enclosed rack is packed with features that installers have been asking for. L-Shaped tie bars feature oblong cutout on both sides of the L to keep cables tidy and well organized.
Hitachi's installation-friendly CP-WU8450A LCD projector is designed to provide maximum presentation impact in mid to large venue applications. It offers a versatile array of innovative, performance-enhancing features along with advanced video display technology providing bold, brilliant colors with incredible image clarity and uniformity. Plus, with motorized zoom, focus and superior lens shift, and a variety of lens options, the CP-WU8450A is at the top of its class when it comes to installation flexibility.
The Microflex® Low Profile Boundary microphone is an ideal table microphone when minimal presence is of high priority. Perfect for meeting rooms, these microphones deliver exceptional sound pickup while barely being noticed. Choose from a selection of colors and pickup patterns for customized table installations.

RELATED PROJECTS

Sharp AQUOS HD LC-90LE657U 90” Class AQUOS HD Series LED Smart TV
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Crestron TSW-1050
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Shure MX395B-LED
×

The Microflex® Low Profile Boundary microphone is an ideal table microphone when minimal presence is of high priority. Perfect for meeting rooms, these microphones deliver exceptional sound pickup while barely being noticed. Choose from a selection of colors and pickup patterns for customized table installations

Crestron DM-MD8X8-RPS
×

A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, CEC signal management, USB signal routing, integrated Ethernet switch, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

Cisco TelePresence SX80
×

The Cisco TelePresence SX80 Video Conferencing Unit provides a powerful and flexible platform for creating the ultimate video collaboration experience. The SX80 was built with the integrator in mind to support flexibility and creativity for customized video collaboration rooms that delight customers.

Polycom SoundStructure C-Series C16 Audio Mixer
×

The SoundStructure C-Series delivers clear, immersive sound, so your video and voice conferences are more productive. The unmatched performance and clarity will delight meeting participants. SoundStructure C-Series also integrates easily with Polycom Group and HDX Microphones, which leads to faster integration and better performance.

Cisco TelePresence SpeakerTrack 60 Camera
×

The SpeakerTrack 60 employs a unique dual-camera approach. With one camera, it quickly locates the active speaker and presents a close-up of that speaker. At the same time, the other camera readies to seek and display the next active speaker. This results in very fast camera switching and an uninterrupted meeting experience.

Temple Boardroom Temple, TX

Audio, Boardroom, Conferencing, Video

This solution contains the latest in digital audio and video technology with a 90" LED flat panel, small button microphones and Cisco's high definition video conference system. With the addition of Cisco's voice tracking camera technology, the SpeakerTrack 60, users can enjoy a fantastic video conferencing experience allowing for a more personal feel. Utilizing premium table microphones, containing red and green LED indicators, as well as ceiling speaker technology with full-rich sound the room has superior audio quality. Simplistic and extremely user friendly automation is delivered by a 10" table top touch panel containing HD graphics and auto sensing technology.



Off Screen Components Used

The Extron XTRA Series XPA 2001 is a half rack 1U, convection cooled power amplifier delivering 200 watts into a 70 volt or 100 volt line. This professional grade amplifier features a 100 dB signal-to-noise ratio with less than 0.1% THD+N. The XPA 2001 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers.
The NE1 provides solid steel construction, extra space on the bottom of the rack for easily mounting small components and two removable 3U blanks on top for ventilation options, this enclosed rack is packed with features that installers have been asking for. L-Shaped tie bars feature oblong cutout on both sides of the L to keep cables tidy and well organized.

RELATED PROJECTS

Sharp AQUOS HD LC-80LE650U 80" Class AQUOS HD Series LED Smart TV
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Crestron TSW-1050 10.1" Touch Screen
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Cisco TelePresence SpeakerTrack 60 Camera
×

The SpeakerTrack 60 employs a unique dual-camera approach. With one camera, it quickly locates the active speaker and presents a close-up of that speaker. At the same time, the other camera readies to seek and display the next active speaker. This results in very fast camera switching and an uninterrupted meeting experience.

Barco ClickShare
×

ClickShare’s universal USB-powered Button and ClickShare app for iOS and Android avoids the unsightly jumble of cables often seen in meeting rooms. It requires no special adaptor or port – so there’s no need to carry additional wires or rummage under the table. And with no cables, you’ll spend less time setting-up and more time being productive. ClickShare couldn’t be simpler. Everything works with the tap of a button, leaving nothing more to figure out. Connecting ClickShare does not alter your screen size or resolution, so what you see on your laptop screen is replicated on the big meeting room screen. When you plug in a ClickShare Button, there’s no software to download and install. You simply accept an executable file and you’re ready to go. Once finished, ClickShare leaves no software on your PC or Mac. Whether you present from a PC, Mac, tablet or smartphone, ClickShare has it covered. As well as the USB-powered ClickShare Button, the ClickShare app for iOS and Android expands meeting effectiveness to include content sharing from mobile devices.

Extron Cable Cubby 600
×

The Extron Cable Cubby® 600 is a durable, metal enclosure that can be mounted into a tabletop or other flat surface. The Cable Cubby's lid slides out of the way when it is fully open and lifts easily to close. When the cables are not being used, they can be stored out of sight while remaining connected to the system, offering a discreet way to access cables and connection points as they are needed. The Cable Cubby 600 is available in a brushed aluminum finish. AC power modules are available for the US, Europe, and other major world markets

Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
×

A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

Cisco TelePresence SX80 Video Conferencing Unit
×

The Cisco TelePresence SX80 Video Conferencing Unit provides a powerful and flexible platform for creating the ultimate video collaboration experience. The SX80 was built with the integrator in mind to support flexibility and creativity for customized video collaboration rooms that delight customers.

Polycom SoundStructure C-Series C16 Audio Mixer
×

The SoundStructure C-Series delivers clear, immersive sound, so your video and voice conferences are more productive. The unmatched performance and clarity will delight meeting participants. SoundStructure C-Series also integrates easily with Polycom HDX and HDX Microphones, which leads to faster integration and better performance.

Mavericks Conference Room Grapevine, TX

Audio, Conference Room, Video

Traditional conference rooms require more than just a place for people to meet. They require a way to collaborate and discuss their business that streamlines productivity. The ‘Mavericks’ conference room contains a large format LED display with touch ability and wired connections at the table for presentations. This room also contains wireless sharing with up to four images on screen and full iOS mirroring. For communication with the customer’s peers and customers, the room is outfitted with high definition video conferencing as well as spectacular sound quality and audio conferencing integration. All of these features are made easy by a simplistic control interface designed to control all aspects of the room as well as lighting and shades.



Off Screen Components Used

A rack-mountable 3-Series® control processor offering immense power, expanded memory, numerous integrated control ports and optional control card expansion slots. Features an isolated control subnet providing a Gigabit Ethernet LAN dedicated for Crestron devices.
The Polycom RealPresence Group Series is the engine that drives enterprise-grade video, voice and collaboration experiences, accelerating decision-making and fostering innovation. Only Polycom delivers video collaboration experiences that bring users closer together and drive meaningful conversation for geographically dispersed teams.
The CONVERGE Pro 840T is a complete conferencing system featuring an automatic, digital matrix mixer and an eight microphone inputs for the sharpest audio experience with the unmatched sound quality you expect from ClearOne. Ideal for collaboration, presentation and distance communications, the expandable CONVERGE Pro 840T solution fits virtually any venue or application with Distributed Echo Cancellation®, Noise Cancellation, First Microphone Priority and the ability to support up to 96 microphones.
The Extron MPA 401 is a quarter rack width, convection-cooled mono amplifier delivering 40 watts rms output power. This UL 2043, plenum rated design meets UL requirements for in-ceiling installations. The MPA 401 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers. Three buffered inputs are available so three separate sources can be connected without altering performance. The Extron exclusive, high efficiency design generates very little heat and allows the amplifier to be convection cooled and operate in environments with little or no ventilation.
THe T3500 is designed primarily for the telepresence market, table T3500 from the new Slim Line brings a clean high-tech look to today's conference rooms. It features a center island for accommodating your electronics grommets/cubby's for easy plug in of laptops or USB keys and displaying on screen.
The CR3030EX is a minimalist design tech-credenza designed for business conference room environments. Featuring three rack bays with twelve rack spaces each and a dedicated heat exhaust fan per bay. Innovative hidden lock design allows for a seamless look while still providing security for your electronics. Can be butted together to span a room or wall.
The Polycom Ceilling Microphone Array provides complete room coverage with superior audio pickup. This microphone array picks up voices in a 360-degree area, giving focus to the active speaker without physical intervention. This microphone supports stereo audio with Polycom Siren 22 audio technology, increases the flexibility of room use by putting electronics in the ceiling instead of the floor or tabletop and connects directly to the Polycom videoconferencing systems and installed audio solutions.

RELATED PROJECTS

Crestron TSW-1050 Touch Screen
×
The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics™. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.
Sharp AQUOS HD LC-60LE661U 60” Class AQUOS HD Series LED Smart TV
×
The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.
Cisco TelePresence Precision 60 Camera
×
Cisco TelePresence Precision Cameras make your face-to-face video meetings lifelike and immediate. The cameras can optimize every telepresence and high-definition video experience with sharpness and clarity. The Cisco TelePresence Precision Camera portfolio offers four powerful cameras with 1080p60 resolution for easy integration into huddle spaces, small-to-large meeting rooms, boardrooms, and special industry projects.
Crestron DMPS3-300-C Digital Media Presentation System 300
×
The DMPS3-300-C is a complete presentation control and signal routing solution for boardrooms and classrooms. Integrating the control system, multimedia matrix switcher, mic mixer, audio DSP, amplifier, and DigitalMedia distribution center all into a single 3-space rackmount package, the DMPS3-300-C affords substantial signal routing flexibility and high-performance signal processing without the need for separate components.
Cisco TelePresence SX80 Video Conferencing Unit
×
The Cisco TelePresence SX80 Video Conferencing Unit provides a powerful and flexible platform for creating the ultimate video collaboration experience. The SX80 was built with the integrator in mind to support flexibility and creativity for customized video collaboration rooms that delight customers.

Foundation Levitt Conference Room Dallas, Tx

Conference Room, Video

Some customers not only need to share a piece of content with their peers, they need to share multiple at the same time. The users of this space can collaborate with each other while sharing up to three different pieces of content from multiple wired and wireless sources. Simple drag and drop automation from a table top touch panel provides quick and easy screen configuration. The room also integrates audio and video conferencing functionality giving its users the ability to reach their colleagues across the country. To avoid cutting a very nice table, but still give customers a great audio experience, Shure's MX Wireless rechargeable table top microphones and full sound ceiling speakers were installed.



Off Screen Components Used

The Shure Microflex® Wireless microphones provides elegant solutions for managing vivid, lifelike sound in AV conferencing environments from custom boardrooms to networked enterprises. Transmitter form factors include handheld, bodypack, boundary and gooseneck options. Power options include Shure rechargeable batteries, docking station, and USB chargers.

RELATED PROJECTS

Polycom Ceilling Microphone Array
×

The Polycom Ceilling Microphone Array provides complete room coverage with superior audio pickup. This microphone array picks up voices in a 360-degree area, giving focus to the active speaker without physical intervention. This microphone supports stereo audio with Polycom Siren 22 audio technology, increases the flexibility of room use by putting electronics in the ceiling instead of the floor or tabletop and connects directly to the Polycom videoconferencing systems and installed audio solutions.

Sharp AQUOS HD LC-90LE657U 90" Class AQUOS HD Series LED Smart TV
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Polycom EagleEye III 12x Camera
×

The Polycom® EagleEye IV 12x cameras are specifically designed for the Polycom RealPresence Group Series video systems. With a completely digital sensor to capture incredible detail, these cameras also have a wide field of view making them flexible enough to use in any room environment, from a small huddle room to a large boardroom. Includes High-definition capture of up to 1080p60 12x or 4x zoom options available, with 180-degree panning - radius a perfect fit for different environments and applications.

Crestron TSW-1050 10.1” Touch Screen
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics™. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Crestron DMPS-300-C Digital Media Presentation System 300
×

The DMPS-300-C is a complete presentation control and signal routing solution for boardrooms and classrooms. Integrating the control system, multimedia matrix switcher, mic mixer, audio DSP, amplifier, and DigitalMedia distribution center all into a single 3-space rackmount package, the DMPS-300-C affords substantial signal routing flexibility and high-performance signal processing without the need for separate components.

Polycom HDX 7000 Video Conference System
×

With Polycom HDX solutions, connecting and collaborating visually with anyone across your organization is as easy as making a phone call. The Polycom HDX Series connects your people and enhances their collaboration. Whether you are holding a simple interview across campus or staging a large project team meeting with members dispersed across the globe, there are HDX solutions that fit the bill.

A-Star Conference Room Grand Prairie, TX

Audio, Conference Room, Video

In today's ever changing, fast pace world manufacturers must be able to stay ahead of their competition and the proper meeting space can contribute. This meeting room consists of multiple large format displays, Polycom video conferencing and Polycom Ceiling Microphone Arrays to provide an excellent environment for presenting and meeting with their partners as well as customers. With the ability of routing any customer desired image, including up to four images on each screen, users can truly streamline their manufacturing process. Hiding the core components in the customers mill work cabinetry provides a clean and space saving solution.



Off Screen Components Used

The Extron XTRA Series XPA 2001 is a half rack 1U, convection cooled power amplifier delivering 200 watts into a 70 volt or 100 volt line. This professional grade amplifier features a 100 dB signal-to-noise ratio with less than 0.1% THD+N. The XPA 2001 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers.
The SRSR Racking System provides easy rear access to equipment connections in millwork, cabinets and flush in-wall installations. Available with a 19" or 23" useable depth, the SRSR system extends and rotates 90º in either direction, making it ideal for smaller systems.

RELATED PROJECTS

Sharp AQUOS HD LC-60LE650U 60" Class AQUOS HD Series LED Smart TV
×
The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Large Huddle Room Ft. Worth, TX

Audio, Huddle Room, Video

In most work environments meeting spaces are extremely important for individuals to come together, share ideas and collaborate to make their business as productive and profitable as possible. This customer, moving into a multi-tenant building in a premium space of Ft. Worth, wanted to make the most of their space by having several ‘Huddle Rooms’. Each room accommodates the needs of content sharing allowing for up to 4 images on screen as desired. This is done wirelessly and through any device the user may have giving them a true BYOD experience. Users can also present using the built in PCs which also provide UC conferencing. Control of the solutions include auto input sensing and small wall mount button pads where needed.



Off Screen Components Used

A 3-gang wall mount Crestron control system with 10 programmable buttons, customizable backlit labeling, LED feedback, volume control knob, and 11 various control ports.

RELATED PROJECTS

Samsung H5003 LED TV
×

Witness a wider range of colors in your favorite movies, shows and videos with Wide Color Enhancer Plus. See every detail of fast action entertainment with Motion Rate 60. Full HD 1080P with realistic detail of Full HD images invites you to enjoy a viewing experience that redefines reality.

Liberty Panelcrafters AV Wall Plate
×

Panelcrafters precision manufactured HDMI and VGA pass through wall plate.

Crestron MPC-M10 Media Presentation Controller
×

A 3-gang wall mount Crestron control system with 10 programmable buttons, customizable backlit labeling, LED feedback, volume control knob, and 11 various control ports.

Small Huddle Room Ft. Worth, TX

Audio, Huddle Room, Video

In most work environments meeting spaces are extremely important for individuals to come together, share ideas and collaborate to make their business as productive and profitable as possible. This customer, moving into a multi-tenant building in a premium space of Ft. Worth, wanted to make the most of their space by having several ‘Huddle Rooms’. Each room accommodates the needs of content sharing allowing for up to 4 images on screen as desired. This is done wirelessly and through any device the user may have giving them a true BYOD experience. Users can also present using the built in PCs which also provide UC conferencing. Control of the solutions include auto input sensing and small wall mount button pads where needed.



Off Screen Components Used

RELATED PROJECTS

Sharp AQUOS HD LC-50LE650U 50” Class AQUOS HD Series LED Smart TV
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Cisco SX20 Telepresence System
×

The Cisco TelePresence SX20 Quick Set is a flexible solution that helps you easily turn any flat panel display into a powerful telepresence system for small to medium-size meeting rooms. The SX20 Quick Set delivers high-definition video quality, multiparty conferencing, and three different camera options to accommodate room size and configurations--all at a value price.

Cisco TelePresence Precision 60 Camera
×

Cisco TelePresence Precision Cameras make your face-to-face video meetings lifelike and immediate. The cameras can optimize every telepresence and high-definition video experience with sharpness and clarity. The Cisco TelePresence Precision Camera portfolio offers four powerful cameras with 1080p60 resolution for easy integration into huddle spaces, small-to-large meeting rooms, boardrooms, and special industry projects.

Cisco TelePresence Precision MIC 20
×

Cisco TelePresence® Microphones provide a range of audio coverage solutions for both integrated video systems and custom video deployments - either on the table or discreetly through the ceiling. The microphones are optimized for voice and designed for use in small to large collaboration meeting rooms with state-of-the-art audio quality.

Rangers Room Grapevine, TX

Audio, Huddle Room, Video

When you need more meeting spaces to collaborate, share content or have a video meeting, Huddle Rooms can be one of the best solutions where space is limited. The ‘Rangers Conference Room’ was converted from an office to a huddle space housing up 4 people. The room includes Cisco high definition video conferencing and wireless as well as wired content sharing on an LED screen. Audio conferencing through a table top phone gives users a quick and simple phone meeting experience. Better lighting, provided and installed by Taurus, allows the far end of a video call to have the best possible viewing of the participants in the Rangers Room. A room scheduling system, including a 4” touch screen with LED indicators mounted outside of the room, allows the office personnel to know when the room is in use. Users can also schedule at the panel and or view the schedule for the upcoming days, weeks and even months.



Off Screen Components Used

A stylish and versatile touch screen with 4.3" touch display, Smart Graphics™, and multiple mounting options. Includes out-of-the-box room scheduling for use with Crestron Fusion RV® Remote Asset Management Software.

RELATED PROJECTS

Shure MX396 Microflex Multi-Element Boundary Microphone
×

The Microflex® Multi-Element Boundary microphone delivers a unique and versatile tool for conference room installations. Clean and simple in appearance, Multi-Element Boundary mics come in two or three element configurations, combining the coverage of multiple microphones into one small, compact package.

Da-Lite Large Advantage Deluxe Electrol Ceiling Recessed Eletric Screens
×

For larger venue installs, the Large Advantage® Deluxe Electrol® is designed to eliminate the extra step of finishing the screen with trim. The Advantage line of projection screens is designed with ceiling trim already in place. Once the screen is installed, the screen’s trim conceals the rough opening eliminating the need to complete additional trim work.

Hitachi CP-WX4021WN Multi Purpose LCD Projector
×

Double, triple or quadruple the brightness levels with Hitachi’s latest Multi Purpose stackable projectors. These versatile and feature rich models can either be stacked vertically or positioned horizontally to deliver superb images at a fraction of the cost of higher brightness models.

Cisco TelePresence Precision 60 Camera
×

Cisco TelePresence Precision Cameras make your face-to-face video meetings lifelike and immediate. The cameras can optimize every telepresence and high-definition video experience with sharpness and clarity. The Cisco TelePresence Precision Camera portfolio offers four powerful cameras with 1080p60 resolution for easy integration into huddle spaces, small-to-large meeting rooms, boardrooms, and special industry projects.

Crestron CP3
×

A rack-mountable 3-Series® control processor offering immense power, expanded memory, numerous integrated control ports and optional control card expansion slots. A compact, rack-mountable 3-Series® control processor with immense power and numerous integrated control ports.

Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
×

A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

Clearone Converge Pro 840T
×

The CONVERGE Pro 840T is a complete conferencing system featuring an automatic, digital matrix mixer and eight microphone inputs for the sharpest audio experience with the unmatched sound quality you expect from ClearOne. Ideal for collaboration, presentation and distance communications, the expandable CONVERGE Pro 840T solution fits virtually any venue or application with Distributed Echo Cancellation®, Noise Cancellation, First Microphone Priority and the ability to support up to 96 microphones.

Pluto & Jupiter Rooms Grapevine, TX

Audio, Multipurpose, Video

These two rooms are outfitted with high definition video projection technology and large recessed screens allowing users to share content on a large scale in a training and collaboration style setting. The customer can reconfigure the tables as desired by a unique integration of floor connectivity for the microphones and A-V interfaces while still making it easy to do so. Integrated video and audio conferencing features bring multiple ways of communication for customers whether it be in a conference room style setting or in a training room table configuration. Individually mutable microphones and superior ceiling speaker technology provide users with the perfect environment to adapt to multiple user’s needs.



Off Screen Components Used

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics™. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.
The Cisco TelePresence C20 Video Conferencing Unit provides a powerful and flexible platform for creating the ultimate video collaboration experience. The C20 was built with the integrator in mind to support flexibility and creativity for customized video collaboration rooms that delight customers.
The Extron XTRA™ Series XPA 2002 is a half rack 1U, convection cooled power amplifier delivering 200 watts into a 70 volt or 100 volt line. This professional grade amplifier features a 100 dB signal-to-noise ratio with less than 0.1% THD+N. The XPA 2002 is an ENERGY STAR® qualified amplifier with an Extron exclusive, highly efficient, advanced Class D amplifier design. It also features patented CDRS™ - Class D Ripple Suppression technology that provides a smooth, clean audio waveform and an improvement in signal fidelity over conventional Class D amplifiers.
The NE1 provides solid steel construction, extra space on the bottom of the rack for easily mounting small components and two removable 3U blanks on top for ventilation options, this enclosed rack is packed with features that installers have been asking for. L-Shaped tie bars feature oblong cutout on both sides of the “L” to keep cables tidy and well organized.

RELATED PROJECTS

Sharp AQUOS HD TV
×

The AQUOS HD LED Smart TVs deliver legendary AQUOS picture quality, with 120Hz refresh rate and 8 million : 1 dynamic contrast ratio for precision clarity during fast-motion scenes. The AQUOS panel's advanced pixel structure gives you crystal clear picture, brilliant color, and captivating detail.

Polycom Ceilling Microphone Array
×

The Polycom Ceilling Microphone Array provides complete room coverage with superior audio pickup. This microphone array picks up voices in a 360-degree area, giving focus to the active speaker without physical intervention. This microphone supports stereo audio with Polycom Siren 22 audio technology, increases the flexibility of room use by putting electronics in the ceiling instead of the floor or tabletop and connects directly to the Polycom videoconferencing systems and installed audio solutions.

Video wall
×

The LG 55LV35A-5B 55"-Class Widescreen Monitor is designed to be used either alone or in a video wall setup up to 15 x 15. It uses SuperSign V software for a dynamic layout, and SuperSign C software for advanced color adjustment and remote monitoring and control via your network or RS232C. It has a temperature-resistant panel for a longer lifespan, and uses IPS technology for a wide 178∞ viewing angle. It also has high brightness uniformity for improved viewing in a video wall setup.

KI Wharton Lectern
×

The top of the lectern has a frosted plexi-glass top that slides open to reveal a storage tray that holds a laptop or an optional touchscreen monitor that controls presentation technology and the complete room environment. The extended wings provide ample room for a speaker notes or personal laptop. Speaker comfort is supported with a gooseneck microphone and halogen note light that the speaker can adjust to his/her preference. Swing-out drink caddies on both the left and right side ensure a speaker has easy access to a beverage. The Wharton lectern adjusts electronically from 37-1/2 to 47in, which accommodates the 5th percentile female to the 95th percentile male. Access to power and data is easy

Crestron CEN-SWPOE-16 16-Port Managed PoE Switch
×

The CEN-SWPOE-16 offers control system networking made easy, providing CrestronÆ guaranteed performance and reliability for a complete Ethernet network of touch screens, control processors, servers, and other devices in a single-space rack mount package. All 16 ports are Gigabit capable to ensure maximum bandwidth for multimedia and critical control data. All ports are located on the rear of the unit while the front panel provides clear indication of each port's status, providing an ideal form factor for use in a typical 19" AV equipment rack. Customizable front panel labeling makes it easy to designate each port with a friendly, descriptive name.

Plano Training Rooms Plano, TX

Audio, Multipurpose, Video

When customers want to have ultimate flexibility in room configuration while still maintaining a fantastic presentation environment, multiple displays and video wall solutions can be the answer. This customer has two Training Room spaces, both with movable tables and a divisible wall for room combining. To achieve all possible table configurations in both divided and combined modes, Taurus used a 3x3 video wall consisting of 55” LEDs as well as (4) 90” LED displays on the side walls. Users can share several different content sources from floor boxes, wall plates, video conferencing and wireless content. Multiple ceiling microphones allow for participant interaction while presenters can be heard through wireless microphones in both video and audio conferencing calls. Auto room configuration via IR sensors create the ultimate ease of use in room combining while auto input detection avoids the need to always be at the controller.



Off Screen Components Used

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.
Cisco TelePresence Precision Cameras make your face-to-face video meetings lifelike and immediate. The cameras can optimize every telepresence and high-definition video experience with sharpness and clarity. The Cisco TelePresence Precision Camera portfolio offers four powerful cameras with 1080p60 resolution for easy integration into huddle spaces, small-to-large meeting rooms, boardrooms, and special industry projects.
A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.

RELATED PROJECTS

AVFI Economy Podium
×

The roll-about economy podium model PD3003 is a smaller compact version of our popular multimedia presentation podiums. To reduce the overall size this unit comes with a large flip-up side shelf and an open front keyboard shelf. Made with furniture grade laminates with large 28" W x 24" D work surface to accommodate monitors, laptops and presentation documents. Also included with slide out keyboard shelf and heavy-duty casters for easy maneuvering.

Da-Lite Large Advantage Deluxe Electrol Ceiling Recessed Eletric Screens
×

For larger venue installs, the Large Advantage® Deluxe Electrol® is designed to eliminate the extra step of finishing the screen with trim. The Advantage line of projection screens is designed with ceiling trim already in place. Once the screen is installed, the screen’s trim conceals the rough opening eliminating the need to complete additional trim work.

Hitachi CP-WU8451 Multi Purpose LCD Projector
×

Double, triple or quadruple the brightness levels with Hitachi’s latest Multi Purpose stackable projectors. These versatile and feature rich models can either be stacked vertically or positioned horizontally to deliver superb images at a fraction of the cost of higher brightness models.

Shure MX Microflex Wireless
×

Microphone Solutions for Enterprise-Scale AV Environments. Microflex® Wireless provides elegant solutions for managing vivid, lifelike sound in AV conferencing environments from custom boardrooms to networked enterprises. Transmitter form factors include handheld, bodypack, boundary and gooseneck. Power options include Shure rechargeable batteries, docking station, and USB chargers.

Crestron TSW-1050 10.1” Touch Screen
×

The TSW-1050 provides a space-saving wall, lectern, or tabletop touch screen featuring a clean, contemporary appearance with edge-to-edge glass and advanced high-definition Smart Graphics™. This touch screen offers an ideal user-interface for controlling all the technology in your boardroom, classroom, courtroom, or command center. Touch screens do away with piles of remote controls, cluttered wall switches, and cryptic computer screens, simplifying and enhancing the way you use technology.

Crestron CP3N
×

A rack-mountable 3-Series® control processor offering immense power, expanded memory, numerous integrated control ports and optional control card expansion slots. Features an isolated control subnet providing a Gigabit Ethernet LAN dedicated for Crestron devices.

CKV Training Room Plano, TX

Audio, Multipurpose, Video

In today’ s training environments users need ultimate flexibility in presenting and communications. This customer has a 3 room training configuration consisting of high definition projector technology and confidence monitors using LED displays. The system automatically detects the patrician walls and the room’ s configuration for audio-visual, but an override is built in for those special considerations. Both wired and wireless sources give users every possible presentation method or connection style. The wireless, rechargeable microphone systems are designed to be used in any of these spaces and in any configuration by simply dragging the desired mics into the room on the touch panel interfaces. Quick and easy disconnect / reconnect of the podiums make the rooms simple to reconfigure.



Off Screen Components Used

A fully modular and expandable 8x8 DigitalMedia matrix switcher featuring redundant power supplies for mission critical applications. Offers ultra-fast digital video and audio switching, and lossless HD multiroom signal distribution, for all types of AV sources. Provides complete management for SD, HD, UHD, 2K, 4K, and computer signals with advanced HDCP support, EDID resolution management, simultaneous 7.1 and stereo audio, H.264 streaming, and a full range of selectable input and output types.
The CONVERGE Pro 880T is a complete conferencing system featuring an automatic, digital matrix mixer and an eight microphone inputs for the sharpest audio experience with the unmatched sound quality you expect from ClearOne. Ideal for collaboration, presentation and distance communications, the expandable CONVERGE Pro 880T solution fits virtually any venue or application with Distributed Echo Cancellation®, Noise Cancellation, First Microphone Priority and the ability to support up to 96 microphones.
The NE1 provides solid steel construction, extra space on the bottom of the rack for easily mounting small components and two removable 3U blanks on top for ventilation options, this enclosed rack is packed with features that installers have been asking for. L-Shaped tie bars feature oblong cutout on both sides of the “L” to keep cables tidy and well organized.

RELATED PROJECTS

ABOUT TAURUS
